Summary Tables of Changes
30 Specification Update
Number
Stepping
Stepping
Stepping
Plans
ERRATA
E-1
M-1
G-2
AH19
X
X
X
No Fix
Code Segment Limit Violation May Occur On 4 Gigabyte Limit
Check
AH20
Fixed
FP Inexact-Result Exception Flag May Not Be Set
AH21
Fixed
Global Pages in the Data Translation Look-Aside Buffer (DTLB) May
Not Be Flushed by RSM instruction before Restoring the
Architectural State from SMRAM
AH22
Fixed
Sequential Code Fetch to Non-canonical Address May have
Nondeterministic Results
AH23
Fixed
VMCALL to Activate Dual-monitor Treatment of SMIs and SMM
Ignores Reserved Bit settings in VM-exit Control Field
AH24
X
X
X
No Fix
REP MOVS/STOS Executing with Fast Strings Enabled and Crossing
Page Boundaries with Inconsistent Memory Types May Use an
Incorrect Data Size or Lead to Memory-Ordering Violations.
AH25
X
X
X
No Fix
Some Bus Performance Monitoring Events May Not Count Local
Events under Certain Conditions
AH26
X
X
X
No Fix
Premature Execution of a Load Operation Prior to Exception
Handler Invocation
AH27
X
X
X
No Fix
General Protection (#GP) Fault May Not Be Signaled on Data
Segment Limit Violation above 4-G Limit
AH28
X
X
X
No Fix
EIP May Be Incorrect after Shutdown in IA-32e Mode
AH29
X
X
X
No Fix
#GP Fault is Not Generated on Writing IA32_MISC_ENABLE [34]
When Execute Disable is Not supported
AH30
Removed Erratum
AH31
Fixed
Performance Monitoring Events for Retired Loads (CBH) and
Instructions Retired (C0H) May Not Be Accurate
AH32
X
X
X
No Fix
Upper 32 bits of „From‟ Address Reported through BTMs or BTSs
May Be Incorrect
AH33
Fixed
Unsynchronized Cross-Modifying Code Operations Can Cause
unexpected Instruction Execution Results
AH34
X
X
X
No Fix
MSRs Actual Frequency Clock Count (IA32_APERF) or Maximum
Frequency Clock Count (IA32_MPERF) May Contain Incorrect Data
after a Machine Check Exception (MCE)
AH35
X
X
X
No Fix
Incorrect Address Computed for Last Byte of FXSAVE/FXRSTOR
Image Leads to Partial Memory Update
AH36
X
X
X
No Fix
Split Locked Stores May Not Trigger the Monitoring Hardware
AH37
Fixed
REP CMPS/SCAS Operations May Terminate Early in 64-bit Mode
When RCX >= 0X100000000
AH38
Fixed
FXSAVE/FXRSTOR Instructions which Store to the End of the
Segment and Cause a Wrap to a Misaligned Base Address
(Alignment <= 0x10h) May Cause FPU Instruction or Operand
Pointer Corruption
