PENTIUM® III XEON™ PROCESSOR AT 600 MHz to 1 GHz with 256KB L2 Cache

APPENDIX

103

Table 55. I/O Signals (Single Driver)

Name Active Level Clock Signal Group Qualified

RP# Low BCLK AGTL+ I/O ADS#, ADS#+1

SMBDAT High SMBCLK SMBus I/O

Table 56. I/O Signals (Multiple Driver)

Name Active Level Clock Signal Group Qualified

AERR# Low BCLK AGTL+ I/O ADS#+3

BERR# Low BCLK AGTL+ I/O Always

BNR# Low BCLK AGTL+ I/O Always

BINIT# Low BCLK AGTL+ I/O Always

HIT# Low BCLK AGTL+ I/O Always

HITM# Low BCLK AGTL+ I/O Always

PICD[1:0] High PICCLK APIC I/O Always
