Intel® Xeon® Processor 3500 Series Datasheet, Volume 1 37

Intel

Xeon

Processor 3500 Series Land Listing

4 Intel

Xeon

Processor 3500

Series Land Listing

4.1 Intel Xeon Processor 3500 Series Land

Assignments

This section provides sorted land list in Tab l e 4 -1 and Table 4 - 2 . Tab le 4- 1 is a listing of

all processor lands ordered alphabetically by land name. Ta b l e 4-2 is a listing of all

processor lands ordered by land number.
