BIOS

Page 4-14

Wake-Up by PCI Card

An input signal form PME on the PCI card awakens the system from S3 suspend

state.

Options: Enabled, Disabled.

Power On by Ring

When enabled, any modem activity awakens the system from soft-off state.

Options: Enabled, Disabled.

USB Wake-Up From S3

This item allows a USB device to wake-up the system from S3 suspend state.

Options: Enabled, Disabled.

Resume By Alarm

When set to Enable alarm resume, you can set the date (of month) and time (hh:mm:

ss), that will awaken a system which has been powered down.

Options: Enabled, Disabled.

S3 KB Wake-up Function

This determines whether or not to enable keyboard/mouse activity to awaken the

system from S3(STR) or S1&S3.

Options: Disabled, Any key, Mouse, Both (Any key+Mouse).
