Intel® Solid-State Drive DC S3500 Series (M.2)

2.0 Product Specifications

2.1 Capacity

Table 1: User Addressable Sectors

Intel SSD DC S3500 Series

Unformatted Capacity

(Total User Addressable Sectors in LBA Mode)

80GB

156,301,488

120GB

234,441,648

340GB

664,212,528

Notes:

1. 1GB = 1,000,000,000 bytes; 1 sector = 512 bytes

2. LBA count shown represents total user storage capacity and will remain the same throughout the life of the drive.

2.2 Performance

Table 2: Random Read/Write Input/Output Operations Per Second (IOPS)

Notes:

1. 4KB = 4,096 bytes

2. 8KB = 8,192 bytes

3. Performance measured using IOMeter* with Queue Depth 32. Measurements are performed on a full Logical Block Address (LBA) span

of the drive.

Table 3: Random Read/Write IOPS Consistency

Specification

Unit

Intel SSD DC S3500 Series

80GB

120GB

340GB

Random 4KB Read

(up to)

Random 4KB Write (up to)

Random 8KB Read

(up to)

Random 8KB Write

(up to)

Notes:

1. Performance consistency measured using IOMeter* based on Random 4KB QD=32 workload, measured as the (IOPS in the 99.9th percentile

slowest 1-second interval)/(average IOPS during the test). Measurements are performed on a full Logical Block Address (LBA) span of the

drive once the workload has reached steady state but including all background activities required for normal operation and data reliability.

2. 4KB = 4,096 bytes

3. 8KB = 8,192 bytes

Specification

Unit

Intel SSD DC S3500 Series

80GB

120GB

340GB

Random 4KB Read

(up to)

IOPS

67,000

Random 4KB Write (up to)

IOPS

8,300

12,000

14,500

Random 8KB Read

(up to)

IOPS 38,000 45,000 45,000

Random 8KB Write

(up to)

IOPS

4,200

6,100

7,300

Product Specification Addendum January 2015

6 331061-002US
