Intel® Solid-State Drive 730 Series

Product Specification December 2014

12 330177-003

2.6 Reliability

The Intel® SSD 730 Series meets or exceeds SSD endurance and data retention requirements as specified in the

JESD218* specification.

Table 8: Reliability Specifications

Parameter

Value

Uncorrectable Bit Error Rate (UBER)

Uncorrectable bit error rate will not exceed one sector in the specified number of bits

read. In the unlikely event of a non-recoverable read error, the SSD will report it as a read

failure to the host; the sector in error is considered corrupt and is not returned to the

host.

< 1 sector per 10

bits read

Mean Time Between Failures (MTBF)

Mean Time Between Failures is estimated based on Telcordia* methodology and

demonstrated through Reliability Demonstration Test (RDT).

≥ 2.0 million hours

Minimum Useful Life/Endurance Rating

The SSD will have a minimum useful life based on a typical client workload assuming up

to 50GB of host writes per day for the 240GB SSD and 70GB of host writes per day for

the 480GB SSD.

5 years

Insertion Cycles

Maximum insertion/removal cycles on 2.5 inch port

250 insertion/removal cycles

Note:

Refer to JESD218 for standards information Based on JESD219 workload.

2.7 Hot Plug Support

Hot Plug insertion and removal is supported in the presence of a proper connector and appropriate operating

system, as described in the SATA* 3.0 specification.

This product supports asynchronous signal recovery and issues an unsolicited COMINIT when first mated with a

powered connector to enable reliable detection by a host system without hardware device detection.
