Intel Desktop Board DH77EB Technical Product Specification

Table 18. Front Panel USB 3.0 Connector

Pin Signal Name Description

1 Vbus Power

2 IntA_P1_SSRX− USB3 ICC Port1 SuperSpeed Rx−

3 IntA_P1_SSRX+ USB3 ICC Port1 SuperSpeed Rx+

4 GND Ground

5 IntA_P1_SSTX− USB3 ICC Port1 SuperSpeed Tx−

6 IntA_P1_SSTX+ USB3 ICC Port1 SuperSpeed Tx+

7 GND Ground

8 IntA_P1_D− USB3 ICC Port1 D− (USB2 Signal D−)

9 IntA_P1_D+ USB3 ICC Port1 D+ (USB2 Signal D+)

10 ID Over Current Protection

11 IntA_P2_D+ USB3 ICC Port2 D+ (USB2 Signal D+)

12 IntA_P2_D− USB3 ICC Port2 D− (USB2 Signal D−)

13 GND Ground

14 IntA_P2_SSTX+ USB3 ICC Port2 SuperSpeed Tx+

15 IntA_P2_SSTX− USB3 ICC Port2 SuperSpeed Tx−

16 GND Ground

17 IntA_P2_SSRX+ USB3 ICC Port2 SuperSpeed Rx+

18 IntA_P2_SSRX− USB3 ICC Port2 SuperSpeed Rx+

19 Vbus Power

Table 19. SATA Connectors

Pin Signal Name

1 Ground

2 TXP

3 TXN

4 Ground

5 RXN

6 RXP

7 Ground

Table 20. S/PDIF Header

Pin Signal Name

1 Ground

2 S/PDIF out

3 Key (no pin)

4 +5 V DC
